Specs:

Focal 100 ICW5T | In Ceiling 70V/100V Speaker Each


• In-wall/In-celling - 2-way coaxial

• Drivers: 5" (13cm) Polyglass Midbass. 1" (25mm) AI inverted dome Tweeter
• Sensitivity (2.83V/1m): 88dB

• Frequency response (+/-3dB): 65Hz-23kHz

• Low frequency point (-6dB) 56Hz

• Nominal impedance 8 Ohm

• Minimal impedance 7.3 Ohms

• Recommended amplifier power 15-100W

• External dimensions (Ø/Depth) 7-1/4"x3-27/64" (184x87mm)

• Cut-Out diameter 7-1/4" (184mm)

• Depth from wall 3-5/8" (91mm)

• Net weight (with front grille) 3.75bs (1.7kg)

• Packing dimensions (WxDxH) 8-1/4 x 8-1/4 x 6-11/16" (270x270x170mm)

• Total weight (with packaging) 6.61lbs (3kg)



Features:

• Product designed and developed in France by Focal

• Compact product with shallow mounting depth

• 100V/70V mode by switch

• Ready-to-paint grille



Overview:

IN-WALL OR IN-CEILING COAXIAL 2-WAY LOUDSPEAKER

Designed and developed in France by Focal, the 100 ICW6-T loudspeaker is composed of a 6’’ (16.5cm) midrange speaker driver with Polyglass cone and a 1’’ (25mm) Aluminium tweeter. Like all the products in the 100-T Series, it has an adjustable transformer which adjusts the power for a 70 volt/100 volt system. The transformer thus makes it possible to link the loudspeakers together and cover a vast listening area!

The 100 ICW6-T speaker driver also has very low directivity, which removes any “shower effect” and creates high-quality, uniform sound throughout the whole space. Compact and with a round or square ready-to-paint grille, the 100 ICW6-T is easy to install and discreet wherever it is positioned.
