Specs:

Samsung Commercial VM55B-U | 55 Inch Ultra Narrow Bezel Video Wall Display

Panel

• Diagonal Size: 55"

• Type: IPS

• Resolution: 1920*1080 (Full HD)

• Pixel Pitch(mm): 0.63mm(H)*0.63mm(V)

• Active Display Area(mm): 1209.6 * 680.4 mm

• Brightness(Typ.): 500 nit

• Contrast Ratio: 1200:1

• Viewing Angle(H/V): 178/178

• Response Time(G-to-G): 8ms

• Display Colors: 8 bit - 16.7M

• Color Gamut: 72%

• Operation Hour: 24/7

• Haze: 25%

  Display

• Dynamic C/R: 45,000:1

• H-Scanning Frequency: 62.7kHz ~ 72.3kHz

• V-Scanning Frequency: 57Hz ~ 63Hz

• Maximum Pixel Frequency: 82MHz

  Connectivity

• Input

  RGB: DVI-D, Display Port 1.2
  Video: HDMI 2.0 (2)
  HDCP: HDCP 2.2
  Audio: Stereo mini Jack
  USB: Only F/W upgrade


• Output

  RGB: DP1.2(Loop-out)
  Audio: Stereo mini Jack


• External Control: RS232C(in/out), RJ45

• External Sensor: Detachable type(IR)

  Power

• Type: Internal: Power Supply: AC 100 - 240 V~, 50/60 Hz

• Max[W/h]: 220W

• Typical[W/h]: 136W

• BTU(Max): 825

• Sleep mode: less than 0.5W

• Off mode: less than 0.5W

  Dimension (mm)

• Set: 1213.5 x 684.3 x 73.1, 47.78" x 26.94" x 2.88" Inches

• Package: 1398 x 844 x 257

  Weight

• Set: 21.2 kg, 46.74 lbs.

• Package: 28.8 kg, 63.49 lbs.

• VESA Mount (mm): 600 * 400 (mm)

• Bezel Width (mm): 2.3mm(U/L), 1.2mm(R/B)

  Special Features

• ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 28%, Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(168hrs Clock Keeping) IP5X tested, EMC Class A, Center IR


Features:

Always-on, space-saving solution with ultra-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VMT-U series. The display’s slim depth and 500 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.

Transform any space with high impact visuals
The slender design and 69.9mm cabinet depth provide flexibility for installation and an ultra-narrow 3.5mm bezel-to-bezel width creates a seamless picture opening endless possibilities for designing a captivating visual experience.

View content from any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.

Vibrant images in any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night - regardless of ambient light.

Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.

Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for displays up to 5x5 using a mobile camera.

Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.

Durable and user-friendly design
IP5x certified, the VMT-U series is dust-resistant and able to withstand a range of environmental conditions without needing to prepare additional enclosure in dusty places. An embedded, centrally located infrared receiver (IR) allows for easier and more flexible user control to the display.

Rigorous testing, robust protection
VMT-U series is delivered in specialized packaging which has passed a rigorous 4-step test to meet ISTA standards, ensuring the display is protected from any potential damage during transit. This provides peace of mind for businesses that the display is ready to function immediately after delivery.

Overview:

Replaces VM46T-U/VM55T-U 3.5mm (B-to-B) ultra-narrow bezel video wall allows seamless display The exceptionally thin cabinet depth provides flexibility to create the exact video wall Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content

Flawless uniformity and vivid viewing experience with ultra narrow bezel video wall displays
