Specs:

Epson Pro Cinema QB1000 | 4K HDR 3300 Lumen 3LCD Laser Projector – White

Specifications

• Projection System Epson 3LCD

• Chip Design (Architecture) 3-Chip

• QB1000W White V11HB23020

• Light Source True Laser Diode Array

• Projection Method Front, Front-Ceiling, Rear, Rear-Ceiling

• Driving Method Poly-silicon TFT Active Matrix, 0.74"-wide panel, 12-bit

• Output Resolution 4K Display Technology1, 3840 x 2160 (dual-axis: 1920 x 1080)

• Maximum Input Resolution 4096 x 2160

• Maximum Refresh Rate 120 Hz

• Supported Resolutions 4K 2160p, 2K Full HD 1080p/i, HD 720p, 576p/i, 480p/i

• Native Aspect Ratio 16:9 widescreen

• Resize Aspect Ratio Support 1.9:1 (4096 x 2160), 21:9 (2560 x 1080), 4:3 (1600 x 1200), 3:2 (720 x 480), 5:4 (720 x 576); compatible with Normal, Full or Zoom Modes

• Color Brightness Color Light Output: 3,300 lumens

• White Brightness White Light Output: 3,300 lumens

• Contrast Ratio Up to and over 5,000,000:1, with Dynamic Contrast in Normal or High Speed setting

• White Balance 13-point temperature adjustment

• Color Reproduction Full-color (up to 1.07 billion colors)

• Size (Projected Distance) 50" to 300" (at 58" to 62'4")

• HDR Color Processing Full 10-bit

• Epson ZX Picture Processor Full 12-bit

• Light Source Life:
  Normal Mode: Up to 20,000 hours
  Medium Mode: Up to 20,000 hours
  Eco Mode: Up to 20,000 hours

  Projection Lens

• Epson VRX Lens 15-element precision glass structure (AGS)

• Type Powered focus/optical zoom/lens position

• F-number 2.0 – 3.0

• Focal Length 22.5 – 46.7 mm

• Zoom Ratio 1 – 2.1

• Throw Ratio Range 1.35 – 2.84

• Lens Shift Vertical: -96.3% to +96.3% (H center, powered) Horizontal: -47.1% to +47.1% (V center, powered)

• Keystone Correction Vertical/Horizontal: ± 30 degrees

• Lens Cover Powered, slide lens shutter

  Interfaces

• 2x HDMI® 2.1 (HDCP 2.3); one supporting eARC/ARC

• 1x USB Type-A (for optical HDMI cable, 300 mA maximum power supply only)

• 1x USB Type-A 5 V, 2.0 A for power and firmware

• 1x Mini USB (service only)

• 1x LAN RJ45 (control only)

• 1x RS-232C (DB-9)

• 1x Trigger Out (On, Off, Anamorphic Wide) 12 V DC, 200 mA maximum (3.5 mm mono or stereo mini-jack)

  Other Features

• Dynamic Range Support HDR102, HLG

• HDR2 Adjustment 16 steps, real-time

• Color Modes Dynamic, Vivid, Cinema, Natural

• Aspect AdjustmentYes (Auto/Full/Zoom/Anamorphic Wide/Horizontal Squeeze)

• Anamorphic Lens Option Compatible with third-party options; Anamorphic Lens Kit sold separately

• Frame Interpolation Input up to 4K at 60 Hz, output up to 4K at 120 Hz

• eARC Audio Compatibility LPCM, supports Dolby® Digital AC-3, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-HD, DTS-HD High Resolution Audio, Master Audio, DTS:X, AAC

• ARC Audio Compatibility LPCM, Dolby Digital (AC-3), DTS, AAC

• Web Control Projector setup and control via web browser

• Operating Temperature 41° to 95° F (5° to 35° C)

• Smart Home Control: PJLink®, Control4® and Crestron® Support

• Power Supply Voltage 100 – 240 VAC ± 10%, 50/60 Hz

• Power Consumption Normal Mode: 341 W, Medium Mode: 301 W, Eco Mode: 206 W

• Fan Noise 22 – 32 dB

• Security Kensington® security lock port

• Parental Controls Power Button Lock hinders projector from being turned on without parental supervision

  Dimensions (W x D x H)

• Projector, Including Feet (Excluding Cable Cover) 20.5" x 17.6" x 7.6"

• Weight: 28.2 lb

• Packaging: 27.25" x 21.75" x 10.5"

• Weight: 49.8 lb

  Remote Control

• Features Front and rear directional

• Operating Distance 32 ft (10 m)

• Operating Angle Front Right/Left: ± 30 degrees

• Upper/Lower: ± 30 degrees

• Rear Right/Left: ± 30 degrees

• Upper/Lower: 0 + 60 degreesemote Control

  What's in the box:

• Epson QB1000 projector

• cable cover

• power cord

• remote control with (2) AA batteries

• Quick Setup Guide

  Eco Features

• RoHS compliant

• Recyclable product6

• Epson America, Inc. is a SmartWay® Transport Partner


Features:

• Stunning 4K Display Technology2

• 3,300 Lumens of Equal Color & White Brightness1

• Unique 3-chip 3LCD Projection Technology

• Impressive HDR10+3

• Powerful Epson QZX Picture Processor


• Laser-Array Light Source- True multi-array laser diodes produce an ideal light source to power the unique 3-chip 3LCD projector engine for incredible picture brightness, black contrast and color accuracy


• UltraBlack™ Technology – Taking full advantage of the laser-array light source, Epson created a proprietary compensation filter that controls the polarization of light itself. This allows Epson to suppress any stray light within the signal to dramatically enhance the overall black density and picture contrast while producing a Dynamic Contrast Ratio exceeding 5,000,000:1


• Epson VRX Cinema Lens – Designed for zero-light leakage, the Epson VRX Cinema Lens utilizes a proprietary 15-element precision glass structure for outstanding image clarity and edge-to-edge focus uniformity. This could be one of the best projector lens technologies Epson has ever developed


• 3-Axis Motorized Lens Shift – Making installation simple, you can precisely shift the lens up to 96% horizontally and up to 47% vertically without any loss in picture distortion or clarity. You can also set the zoom and focus, then store all the settings in one of 10 lens memory presets


• HDMI® 2.1 – Supports the full 40 Gbps bandwidth for accepting 4K HDR content up to 120 Hz. Along with ARC and eARC support, this allows for outstanding compatibility with the latest AV receivers and next-generation gaming consoles


• Native 120 Hz Refresh Rate – Refresh rates up 120 Hz allow for smoother motion for supported content while providing the option for impressive frame interpolation for content below 120 Hz


• Epic for Gaming – Gaming up to 4K at 120 frames per second, along with input lag times below 20 ms, allow for serious gamers to take full advantage of the latest generation of gaming consoles and even higher-end gaming PCs; Auto Low Latency Mode minimizes input lag for smooth and responsive gaming


• World-Class Warranty & Support – Standard 3-year limited warranty with 2-business day full unit replacement, including free shipping. And all Epson professional theater projectors come with free lifetime technical phone support


• ISF® Certified – The Imaging Science Foundation has been setting the display standards since 1994 and has been dedicated to improving the quality of electronic imaging. Epson shares this passion for image quality and has developed technologies to allow an ISF Certified Technician to professionally calibrate the Epson QB1000 projector to the highest level of image quality



Overview:

Reimagine Projection.

Introducing a new generation of high-lumen theater projection from Epson.

The all-new Epson QB1000 4K 3LCD Laser Projector with HDR.

Developed specifically for premium home theater experiences, the Epson QB1000 produces a stunning 4K HDR picture with an incredible 3,300 lumens of color brightness and white brightness1, setting a new benchmark for theater picture quality.

Incorporating our most advanced projection technologies to date, the QB1000 combines proprietary 4K display technology2 with our unique 3-chip 3LCD laser-array technology to produce a full 8.29 million pixels on-screen—resulting in a picture with stunning clarity and color brightness.

And, when driven by our proprietary Epson QZX Picture Processor, the Epson QB1000 optimizes the incredible brightness, color accuracy and black contrast to faithfully display all your content the way the director intended.

Make no mistake, the Epson QB1000 Laser Projector reimagines the premium 4K HDR theater experience and could quite possibly be the best premium theater projector ever developed by Epson.
